Hardray
The HARDRAY brings pure cross-country vibes to the trail: direct handling, balanced geometry and a robust aluminium frame deliver control and riding fun on any surface. Powerful Yamaha drives with up to 85 Nm and an integrated battery with up to 800 Wh provide the boost you need for long tours, steep climbs and new routes. An honest e-hardtail for anyone who just wants to get on the bike and ride.
Mehr Details
Facilities
Allgemein
frame shape
Unisex
Einsatzbereiche
Gelände
frame size
M
weight
23,9 kg
permissable total weight
130 kg
Antriebssystem
motor
Yamaha PW-S2, 250/600 W, 75 Nm
charger
Smart Charger, 4 A
display
Yamaha Display A2, LCD, Micro-USB
Akku-Montage
Intube herausnehmbar
Bremsen
Bremsen
Hydraulische Scheibenbremse
brake rear
Shimano BR-MT200, 2-piston, hydr. disc brake
brake front
Shimano BR-MT200, 2-piston, hydr. disc brake
rotor front
Shimano SM-RT10, 180 mm, Center Lock
rotor rear
Shimano SM-RT10, 180 mm, Center Lock
Ergonomie
seatpost
Raymon, 34,9 mm
grips
Raymon MTB, lock on
handlebar
Raymon Riser 31,8 mm, Sweep: 9 °, Rise: 20 mm
saddle
Raymon 145 HM Fit
stem
Raymon 31,8, Ahead
Laufräder
wheel size
29"
wheelset
Raymon VR23/DT210, 15x110/12x148 mm
tyre
Schwalbe Smart Sam Active, 60-622, 29x2.35
Rahmenset
frame
29", Alloy 6061, removeable battery, boost
fork
SR Suntour XCM32, 120 mm, tapered
Schaltung
rear derailleur
Shimano Cues, LG, RD-U4000, 9-S
shift lever
Shimano Cues, SL-U4000, Rapidfire Plus
chain
Shimano CN-LG500
cassette sprocket
Shimano CS-LG300, 11-46T
Streetkit
side stand
KSA40, compatible
