Facilities
Allgemein
frame shape
Wave
frame size
M
Einsatzbereiche
Feld-/Waldwege
weight
28,6 kg
permissable total weight
150 kg
Antriebssystem
motor
Bosch Performance Line CX, 250/750 W, 120 Nm
battery
Bosch PowerTube, 800 Wh, 36 V
charger
Bosch Charger, 4 A
display
Bosch Kiox 300
Akku-Montage
Intube herausnehmbar
Bremsen
brake rear
Shimano XT, BR-M8120, 4-piston, hydr. disc brake
rotor rear
Shimano SM-RT54, 180 mm, Center Lock
brake front
Shimano XT, BR-M8120, 4-piston, hydr. disc brake
rotor front
Shimano SM-RT54, 180 mm, Center Lock
Bremsen
Hydraulische Scheibenbremse
Ergonomie
handlebar
Raymon Riser 31,8 mm, Sweep: 15 °, Rise: 30 mm
saddle
Raymon MIMA VM fit
seatpost
Raymon, 34,9 mm, Dropper Post
stem
Raymon, 31,8, Ahead, adjustable
grips
Raymon Ergo, lock on
Laufräder
wheel size
29"
wheelset
Raymon VR24/DT210, 15x110/12x148 mm
tyre
Schwalbe Marathon E-Plus, Reflex, 55-622, 29x2.15
Rahmenset
frame
29", Alloy 6061, removeable battery, boost
fork
RockShox Recon Gold RL, air, 80 mm, tapered
Schaltung
rear derailleur
Shimano Deore XT, RD-M8100, 12-S
shift lever
Shimano Deore, SL-M8100, Rapidfire Plus
chain
Shimano CN-M6100
cassette sprocket
Shimano CS-M7100, 10-51T
Streetkit
carrier
Raymon, MIK HD, 27 kg
front light
Litemove SEC-150, 150 lx
side stand
Ursus MOOI, KSA40, adjustable
